TECHNICAL SPECIFICATIONS
| V-6 | |
| BODY | |
| Construction | Unibody |
| Final Assembly Location | Oakville, Ontario |
| POWERTRAIN AND CHASSIS | |
| ENGINE | |
| Type | 3.5L DOHC 24-valve V6 |
| Manufacturing Location | Lima Engine Plant, Ohio |
| Configuration | 60 degree V6, aluminum block and heads |
| Intake Manifold | Composite, split plenum |
| Exhaust Manifold | Cast Iron |
| Crankshaft | Forged steel |
| Redline | 6700 RPM |
| Idle Speed in Drive | 620 RPM (640 with trailer tow package) |
| Throttle Body | 65mm, electronic |
| Valvetrain | DAMB, 4 valves per cylinder, intake variable camshaft timing |
| Valve Diameter | Intake: 37mm; Exhaust: 31mm |
| Pistons | High temperature cast aluminum alloy with low-friction coated skirts, low tension rings |
| Connecting Rods | Cracked powder metal |
| Ignition | Pencil Coil |
| Bore x stroke | 3.6 x 3.4 in/ 92.5 x 86.7 mm |
| Displacement | 213 cu in/ 3.496 cc |
| Compression ratio | 10.3:1 |
| Horsepower | 250 @ 6250 |
| Horsepower per liter | 71.5 |
| Torque | 240 lb-ft @ 4500 |
| Recommended fuel | 87 Octane |
| Fuel capacity | 20 gallons |
| Fuel Injection | Sequential multi-port fuel injection |
| Emission Control | Closed loop with catalyst |
| Emissions (tailpipe/evaporation) | |
| Federal standards | Fed: Tier 2/Bin5, LEV II |
| California standards | Calif: ULEV II |
| Oil Capacity | 5.5 quarts, with filter |
| Recommended Oil | GF4, 5W-20 |
| DRIVETRAIN | |
| Layout | FWD (Optional AWD) |
| TRANSMISSION | |
| Standard | 6-Speed Automatic |
| Gear Ratios | |
| 1st | 4.484 |
| 2nd | 2.872 |
| 3rd | 1.842 |
| 4th | 1.414 |
| 5th | 1.000 |
| 6th | 0.742 |
| REV | -2.882 |
| Final Drive | FWD: 2.77; AWD: 3.16 |
| SUSPENSION | |
| Front | Macpherson strut and L-shaped lower control arm with isolated subframe and stabilizer bar |
| Rear | Independent suspension with trailing blade, integrated knuckle and lateral links, isolated subframe and stabilizer bar |
| STEERING | |
| Type | Power rack and pinion |
| Steering column | Tilt-telescope |
| Ratio | 17.5:1 |
| Turns lock-to-lock | 3.15 |
| Turning circle curb-to-curb | 11.5 m (37.7 ft) |
| BRAKES | |
| Type | 4-wheel ABS (4 channel); Optional AdvanceTrac® with Roll Stability Control (RSC®) |
| Front | Disc |
| Swept area | FWD (63.5 in2) AWD (66.8 in2) |
| Rear | Disc |
| Swept area | 51.3 in2 |
| Power assist | Yes |
| TIRES AND WHEELS | |
| P235/65R17 all-season BSW on 17x7-in. steel with cover (SE) | |
| P235/65R17 all-season BSW on 17x7.5-in. painted aluminum (SEL, optional SE) | |
| P245/60R18 all-season BSW on 18x7.5-in. painted aluminum or aluminum with chrome (optional SEL) | |
| Recommended tire pressure (front/rear) | 35 psi |
| DIMENSIONS (inches unless otherwise noted) (All dimensions are Preliminary) | |
| EXTERIOR | |
| Wheelbase | 111.2 |
| Overall length | 185.7 (SE); 186.5 (SEL) |
| Overall width | 75.8 |
| Overall height | 67.0 (w/o roofrack); 68.7 (w/roofrack) |
| Track width, front/rear | 65.2/64.9 |
| Ground clearance | 8.0 |
| Approach angle | 16 deg |
| Departure angle | 22 deg |
| Ramp breakover angle | 14 deg |
| Cargo Volume behind front row | 68.7 cu ft |
| Cargo Volume behind second row | 32.0 cu ft |
| INTERIOR | |
| Seating capacity | 5 passenger |
| Headroom | |
| Front row | 40.0 (w/o moonroof); 37.8 (w/moonroof) |
| Second row | 39.3 (w/o moonroof); 38.6 (w/moonroof) |
| Legroom | |
| Front row | 40.7 |
| Second row | 38.1 |
| Shoulder room | |
| Front row | 58.9 |
| Second row | 58.8 |
| Hip room | |
| Front row | 54.8 |
| Second row | 56.1 |
| WEIGHTS AND CAPACITIES (pounds unless otherwise noted) | |
| Maximum towing capacity (when properly equipped) | Class II (3500 lbs) |
| Maximum payload (when properly equipped) | |
| FWD | SE: 1011; SEL: 1023 |
| Base curb weight | |
| SE | 4098 |
| SEL | 4086 |
| Weight distribution (f/r) | 60/40 |
| MAJOR STANDARD EQUIPMENT | |
| SE Model | Anti-lock brakes, spoiler, remote keyless entry, manual fold power mirrors, cloth bucket seats, 2nd row 60/40 split-fold-flat bench seats with center head restraint, 3-point belts in all positions, front row height adjustable seat belts, BeltMinder® (front row), Personal Safety System™, child safety locks, LATCH, front and rear floormats, front console, manual air conditioning, power windows with one-touch down driver, power locks, speed control, premium AM/FM/Single CD/MP3 capable audio system and 4 speakers |
| SEL adds | Fog lamps, 6-way power driver seat, overhead console, premium CDx6 with 9 speakers, steering wheel audio controls, unique Interior treatments, message center/compass, chrome exhaust tips, dual illuminated visors |
| OPTIONS | |
| Interior | Side air bags, Safety Canopyâ„¢, auto-dimming rearview mirror, premium CDx6, audio jack in center console, SIRIUS Satellite radio SEL only options: Leather seats, 6-way power passenger seat, passenger seat fold flat, heated seats, memory driver seat, remote release on 2nd row fold-flat seats, dual electronic automatic temperature control with air filter, manual fold power heated side mirrors with puddle lamps and memory, audiophile sound, DVD entertainment system, navigation system, redundant climate controls on steering wheel |
| Exterior | AWD, AdvanceTrac® with Roll Stability Control™, Class II trailer tow package, automatic headlamps, roof side rails, 17" painted aluminum wheels, keyless entry pad SEL only Options: Panoramic Vista Roof™, Reverse Sensing System, 18" chrome clad or painted aluminum wheels |
| OTHER | |
| Exterior color | Blazing Copper, Crème Brulee, Redfire, Ebony, Carbon, Dune Pearl, Pewter, Light Sage, Dark Amethyst |
| Interior trim | Medium Light Stone, Camel, Charcoal Black |
| WARRANTY INFORMATION | |
| Warranty | 3-year, 36,000 bumper-to-bumper warranty |
